CAMPER

7. CAMPER CHARACTER SET

The following characters are already defined in stack 7 when CAMPER is entered.

Character	Array	Number of Points	Character	Array	Number of Points
A	1	8	U	21	6
B	2	12	V	22	4
C	3	8	W	23	6
D	4	8	X	24	4
E	5	8	Y	25	6
F	6	6	Z	26	4
G	7	10	,	27	6
H	8	6	.	28	6
I	9	6	-	29	2
J	10	12	0	30	10
K	11	6	1	31	6
L	12	4	2	32	8
M	13	6	3	33	14
N	14	4	4	34	6
O	15	10	5	35	10
P	16	8	6	36	12
Q	17	12	7	37	4
R	18	14	8	38	16
S	19	14	9	39	12
T	20	4	space	40	2

Figure 11
